| MODEL No. | RATED | L(mm) | ||||
|---|---|---|---|---|---|---|
| OUTPUT(W) | VOLTAGE(V) | CURRENT(A) | SPEED(RPM) | TORQUE(Kgf.cm) | ||
| MGK6S-H15D | 15 | AC220 | 0.09 | 2,000 | 0.73 | 61 |
| MGK6S-H40D | 40 | AC220 | 0.23 | 2,000 | 1.95 | 61 |
| MGK6S-H60D | 60 | AC220 | 0.34 | 2,000 | 2.92 | 76 |
| MGK6H-H15D | 15 | AC220 | 0.09 | 3,000 | 0.49 | 61 |
| MGK6H-H40D | 40 | AC220 | 0.23 | 3,000 | 1.30 | 61 |
| MGK6H-H60D | 60 | AC220 | 0.34 | 3,000 | 1.95 | 76 |
| MGK6S-B15D | 15 | DC24 | 0.96 | 2,000 | 0.73 | 61 |
| MGK6S-B40D | 40 | DC24 | 2.56 | 2,000 | 1.95 | 61 |
| MGK6S-B60D | 60 | DC24 | 3.85 | 2,000 | 2.92 | 76 |
| MGK6H-B15D | 15 | DC24 | 0.96 | 3,000 | 0.49 | 61 |
| MGK6H-B40D | 40 | DC24 | 2.56 | 3,000 | 1.30 | 61 |
| MGK6H-B60D | 60 | DC24 | 3.85 | 3,000 | 1.95 | 76 |
